| Chip |
chip |
T21 |
| CPU |
single core 1.2GHz |
| RAM |
Embedded 16bit@400Mhz DDRII;512M |
| Image sensor |
sensor type |
1/2.7inch CMOS sensor |
| resolution |
1920×1080(2MP) |
| minimum illumination |
0 |
| Lens |
lens type |
full glass lens |
| lens |
focal length:3.6MM circle dia:2.4 |
| view angle |
60° |
| night vision |
Dual IR-Cut filter ,6pcs infrared light |
| night vision distance |
25 M |
| Network |
protocol |
HTTP,FTP,TCP/IP,UDP,SMTP |
| DHCP, PPPOE, DDNS, UPnP |
| wire internet |
support |
| wireless internet |
WIFI(IEEE 802.11b/g/n) |
| wi-fi speed |
150Mbps(Max) |
| wi-fi |
WIFI intelligent (smart link) |
| P2P connect |
support |
| Software |
video compression type |
H.264,MJPEG |
| resolution |
1920 x1080(1080P),640 x 480(VGA) |
| frame rate |
25fps,15fps |
| code rate |
dual |
| multi media |
YES |
| Motion detection |
YES |
| E-mail/FTP alarm |
YES |
| SD fit in |
YES |
| SD storage |
YES |
| FTP upload video recode |
NO |
| UPnP |
YES |
| DDNS |
YES |
| ONVIF |
support |
| Storage |
TF card |
Max 64GB |
| Audio |
Two way Audio |
YES |
| internal microphone |
YES |
| External microphone |
no |
| Audio compression format |
adpcm |
| internal speaker |
YES |
| External speaker |
NO |
| Waterproof performance |
waterproof |
YES |
| IP grade |
IP6 |
| Specification |
Power |
DC12V/2.0A |
| Size(mm) |
200(L) x115(W) x80(H) |
| NW(g) |
450 |
| Humidity |
20%~85%( Non-condensing) |
| Temperature |
–10°C~60°C |
| Storage humidity |
0%-90%(Non-condensing) |
| Color |
black and white |
| monitor software |
System |
IPhone, Android, windows PC |
| APP |
Tuya Smartlife |
